Description
ADVANTAGES
No privacy disclosure.
High detection accuracy and low false alarm rate.
Detects person and non-person in the area.
Non-contact posture detection.
Small size, light, easy installation to embed to other devices.
MAIN FEATURES
FALL DETECTION. Warninng if a person falls down to the floor. Squating or lying down does not trigger alarms.
TRESPASS ALERT. Active warnings in case of a burglar.
OVERSLEEPING. Active warnings if the resident is still in bed longer than their normal schedule.
WANDERING ALERT. Active warnings if the resident is outside and not back regularly.
EXTENDED TOILETING. Active warnings if the resident uses the toilet room longer than expected.
BEDTIME NOTIFICATION. Active notifications if the resident is still up past the set time.
SEDENTARY NOTIFICATION. Active notifications if the resident has been sitting for too long.
ADL REPORT. Better insight into the resident’s day to day routine.
DEVICE OFFLINE. Active alerts if the device is offline.
SPECIFICATIONS
ITEMS
PARAMETERS
Model
PT-CF70T
Frequency band
60GHz (FCC certified)
Detection range
Up to 7m/23ft.
Effective field of view (horizontal)
within +45°
Target speed range
within +5m/s
System power
Operating temprature
5V DC 2A
-10-70*C/14-122*F
Extermal dimension of the unit
148x105x24mm/ 58x4.1x0.9in
Weight of the unit (approx.)
260g /9.2oz
IP rating
IP54
Communication protocol
TCP/SDK
Network connection
WiFi
Installaion height
1. 4m~2.2m/4.5 f.to 7.2ft.
APPLICATIONS
